--Product Description
T1130
PingYun T1130 is our hot sell products,it is very popular in all over the world,it also has widely used to villa,residential house,prefabricated house and pavilion etc.
| Style | Material | Width | Length | Thickness | Weight | Quantity |
| T1130 | UPVC | 1130mm | Max 11.8m | 1.5mm | 2.8kg/sqm | 9500sqm/ 40HQ |
| T1130 | UPVC | 1130mm | Max 11.8m | 2.0mm | 3.8kg/sqm | 7200sqm/ 40HQ |
| T1130 | UPVC | 1130mm | Max 11.8m | 2.5mm | 4.8kg/sqm | 5500sqm/ 40HQ |
| T1130 | UPVC | 1130mm | Max 11.8m | 3.0mm | 5.8kg/sqm | 4300sqm/ 40HQ |
R101
R101 style is a successful profile. With same cost, the purlin distance of RlOl will be 10% larger than T1130. Another point, the cover effective rate of R101 is 94.39%, it is better than T1130 (92.93%), so it will save about 1.46% roof cost for you at least.
| Style | Material | Width | Length | Thickness | Weight | Quantity |
| R101 | UPVC | 1070mm | Max 11.8m | 1.5mm | 2.8kg/sqm | 9500sqm/ 40HQ |
| R101 | UPVC | 1070mm | Max 11.8m | 2.0mm | 3.8kg/sqm | 7200sqm/ 40HQ |
| R101 | UPVC | 1070mm | Max 11.8m | 2.5mm | 4.8kg/sqm | 5500sqm/ 40HQ |
| R101 | UPVC | 1070mm | Max 11.8m | 3.0mm | 5.9kg/sqm | 4300sqm/ 40HQ |
HT940
HT940 are the first batch of products designed and produced by our company. Once they are put into the market, they have been highly praised by the majority of users and are widely used in various buildings.
| Style | Material | Width | Length | Thickness | Weight | Quantity |
| HT940 | UPVC | 940mm | Max 11.8m | 1.5mm | 2.8kg/sqm | 9500sqm/ 40HQ |
| HT940 | UPVC | 940mm | Max 11.8m | 2.0mm | 3.8kg/sqm | 7200sqm/ 40HQ |
| HT940 | UPVC | 940mm | Max 11.8m | 2.5mm | 4.8kg/sqm | 5500sqm/ 40HQ |
| HT940 | UPVC | 940mm | Max 11.8m | 3.0mm | 5.9kg/sqm | 4300sqm/ 40HQ |
Long-lasting Color (at least 30 years)
The product features ultra durability in natural environment.Even under tough conditions of exposure to UV,high temperature and freezing coldness,it still keeps stable color.
Excllent Anti-corrosion performance
Synthetic Resin Tile can resist longterm acid ,alkali and salt corrosion ,etc.Tests have proved that there would be no chemical reaction after soaking in salt and alikali and various acid under 60% .It is ideal for application in areas where acid rain is common.
Good Waterproofing Performance
Synthetic Resin Tile selects highly weater-resistant resin,which is dense and absorbing no water,with no pore penetration problem.The product is 45% wider than traditional tiles with less roof contact,so synthetic resin,s waterproof performance has greatly increased than traditional tiles.
Strong Fire Resistance
Belonging flame retardant material,with fire resistance ≥ B1 as tested by national authoritative departments according to GBB8624-2006 standard.
Excellent Heat Insulating Property
The heat conductivity coefficient is 0.325w/m.k,about 1/300 of clay tile ,1/50 of cement tile,and 1/2000 of thick color steel tile.Therefore without condidering ading heat-preserving layer ,the heat insulation and heat preservation of synthetic resin tile can still be optimized.
Good sound insulation
Tests have proved that synthetic resin tiles have excellent noise absorption function when suffered heavy rains and strong winds.
Product test report
Our products cover a full range of plastic roof sheet, including resin roof tile,pvc&upvc roof sheet, pvc hollow sheet,FRP roof sheet,polycarbonate sheet and all kinds of transparent roof sheet.Based on these roof tiles,we have the most complete wave designs all over the china,
What you want is just we have.
As a professional roofing solutions provider,we can effectively solve the roofing problems like heat proof,acid corrosion,light transmission,waterproofing for our customer.In addition ,in order to ensure the product quality,we have adopted the most advanced production procedure with the most advanced testing equipments, of course,the important thing is to carry out the strict testing for raw materials.
Company profile
1. Factory's Scale
Area covered 25000 m2
Month Capacity 100 containers
200 Skilled employ
22 Production Lines
We have totally 22 production lines to meet customers demand for large orders and different styles.
2. Sales Volume
Occupy 35% market share
Sales $16.2 million yearly
Ship container monthly
Continuous supply to large distributors
3. Perfect products
We have over 10 years of production and export experience and have been improving our technology and using excellent raw materials, our products are of high quality.
We have many large distributors in different countries, they keep placing orders and the market is selling well.
4. 10 days lead time
Generally, we could finish the production of goods in 10 days.
5. Production diversification
We could produce different color, width, thickness,length and waveform for various application and climate.
You could find almost all the styles in our company and we often develop new waveforms.
6. Government cooperator
We are supplier of many government projects like 2008 Olympic Game project, Guangzhou Asian Games and South market.
7. Guarantee and Quick feedback for after-sales
The warranty period of our product is 10 years.
Please contact us in time when you have any questions.
8. Free training for installation
We have detailed installation guide to help you.
9. Strict quality control system
We have several links to ensure quality in the process of production and loading.
10. OEM service
If you want to produce unique waveform, we can provide help in mold and production.
Q1. Can I have a sample?
A: Yes, free samples are available, we only need customer to afford the express freight.
Q2. What about the delivery time?
A: Mass production needs 10days within 10000 square meters.
Q3. Do you offer guarantee for the products?
A: Yes, we offer 10 years warranty to our products.
Q4. What colors can you produce?
A: We have many common colors like white, blue, brick red, green, grey, etc and also could customize special colors for you.
Q5. What length can you produce?
A: We could customize length for you. Max length of 5.8 meters for 20 feet container and 11.8 meters for 40 feet container.
Q6. What category do you have?
A: We mainly have Spanish and Roma styles for residential house, PVC trapezoidal and wave styles for factory and warehouse, PVC hollow roof&wall sheet for kinds of buildings, PVC translucent roof sheet for day lighting and so on.
Q7. What are the applications of PVC roof sheet ?
A: PVC roof sheet can be used in farm construction, paper mill construction, site construction, warehouse construction, factory construction, garage construction, winery, brick factory, chemical factory and other almost all kinds of environmental projects
